104A Naval Shock-Proof Water Gauge In Stock

Description:

104A Naval Shock-Proof Gauge



This unit meets the high shock requirements of MIL-S-901C, and the vibration requirements of MIL-STD-167, for Type 1 vibration up to 25CPS  **(certified test reports available upon request)**



  • Unit per MIL- l -20037-B
  • Navy approved.
  • Automatic type – quick closing.
  • Each unit individually hydrostatically tested at 450 psi.
  • Unit is of bronze construction with “monel” trim, “viton” seals, & “polycarbonate” tube.
  • Flanges are integral to bodies and are per A.S.A. standards for 3/4″ 150# flanges.  Different flanges available upon request.
  • Unless otherwise specified, unit will be shipped complete with “polycarbonate” tube for 24″ centers.
  • Upon request, this unit can also be supplied with “Pyrex” high pressure gauge glass with “Class B” protective shield.



**When ordering gauge glass & guard rods, the center-to-center distance between the upper & lower valve connections must be specified**
