Transparent & Reflex Flat Gauge Glass Kits | Boiler Supplies Macbeth Plain Transparent & Reflex Glass
MACBETH Gauge Glass is considered by many to be the “Standard of the Industry”. These high quality gauge glasses are for use in armored-type gauge assemblies for observation of high temperature and high pressure liquid levels. Safety and quality starts with the use of special quality borosilicate glass that is manufactured under carefully controlled conditions. The glass is tempered to provide high strength and has a low degree of thermal expansion to resist thermal shock.
Type A - Plain Glass is designed for moderate-pressure
steam boilers and liquid level indicators.
Type A - High Pressure is controlled to tighter flatness
tolerances to be used in higher pressure applications.
Type B - Reflex Glass is made for ease in determining liquid
levels, especially in clear fluids. The glass has vertical
prisms extending the full viewing length of the glass.
The prism side faces the liquid, and the sections of the
prisms not covered in liquid reflect light brilliantly. The
sections covered by liquids appear dark in contrast.
SPECIFICATIONS
| Part # |
Size Type A - Plain Glass |
Description | Weight | Price | Qty | |
|---|---|---|---|---|---|---|
| 3400MB-04T | 190mm x 34mm x 17mm | #4 Macbeth Plain Transparent Glass | 1.00 | $28.00 | Add to Cart | |
| 3400MB-05T | 220mm x 34mm x 17mm | #5 Macbeth Plain Transparent Glass | 1.00 | $31.00 | Add to Cart | |
| 3400MB-06T | 250mm x 34mm x 17mm | #6 Macbeth Plain Transparent Glass | 1.00 | $33.00 | Add to Cart | |
| 3400MB-07T | 280mm x 34mm x 17mm | #7 Macbeth Plain Transparent Glass | 1.00 | $36.00 | Add to Cart | |
| 3400MB-08T | 320mm x 34mm x 17mm | #8 Macbeth Plain Transparent Glass | 1.00 | $39.00 | Add to Cart | |
| 3400MB-09T | 340mm x 34mm x 17mm | #9 Macbeth Plain Transparent Glass | 1.00 | $42.00 | Add to Cart |
| Part # |
Size Type B - Reflex Glass |
Description | Weight | Price | Qty | |
|---|---|---|---|---|---|---|
| 3400MB-03R | 165mm x 34mm x 17mm | #3 Macbeth Reflex Glass | 1.00 | $25.00 | Add to Cart | |
| 3400MB-04R | 190mm x 34mm x 17mm | #4 Macbeth Reflex Glass | 1.00 | $25.00 | Add to Cart | |
| 3400MB-05R | 220mm x 34mm x 17mm | #5 Macbeth Reflex Glass | 1.00 | $29.00 | Add to Cart | |
| 3400MB-06R | 250mm x 34mm x 17mm | #6 Macbeth Reflex Glass | 1.00 | $31.00 | Add to Cart | |
| 3400MB-07R | 280mm x 34mm x 17mm | #7 Macbeth Reflex Glass | 1.00 | $35.00 | Add to Cart | |
| 3400MB-08R | 320mm x 34mm x 17mm | #8 Macbeth Reflex Glass | 1.00 | $37.00 | Add to Cart | |
| 3400MB-09R | 340mm x 34mm x 17mm | #9 Macbeth Reflex Glass | 1.00 | $40.00 | Add to Cart |
