Liquid Level Sight Gauges & Water Gauges | Boiler Supplies Clark Reliance Boiler Trim Water Column Parts Clark Reliance BG402S, BG403S, BG404S Bronze Valves
Clark Reliance Bronze Water Gage Valve Set is designed and manufactured for demanding applications. Designated as high-grade valves, all models feature valve bodies & packing nuts of ASME Code Bronze. Additional design features include an 18-position gage lever, integral seats & choice of screwed or flanged connections. Valve control is speeded by quadruple stem threads that allow full open/closed with only one-quarter turn.
Specification Data
Chains & handles that indicate open/closed positions are provide, as required by the ASME BOILER CODE. Lower valves employ a 3/8" pipe tap for blowdown. A complete valve set included upper & lower valve, pyrex tubular glass & guard rods (if mounting centers are specified) & two 5ft. chain lengths. Valve model numbers are stamped on the top of upper valve.
NOTE: Power Plus does not recommend tubular glass for use above 250 WSP
| Part # | Connection |
Max Pressure |
Description |
Net Weight Per Set |
|
|---|---|---|---|---|---|
| BG 402S | 1/2" NPT | 250 PSI | Bronze Water Gage Valve Set | 8 lbs | Add to RFQ |
| BG 403S | 3/4" NPT | 250 PSI | Bronze Water Gage Valve Set | 8 lbs | Add to RFQ |
| BG 404S | 3/4" NPT | 450 PSI | Bronze Water Gage Valve Set | 8 lbs | Add to RFQ |
