Heat Exchanger Replacement Tube Bundles | Boilersupplies Armstrong Tube Bundles For Shell & Tube Heat Exchangers Armstrong "W" Liquid to Liquid Tube Bundle
Tube bundles are replaceable coils inside the shell of the Heat Exchanger. This is the most common part that fails and most often the U-tubes can be vulnerable to corrosion and failure. The tube bundle coil can be manufactured with many types of materials including copper, CuNi, stainless steel along with naval brass and carbon steel.
Boilersupplies.com manufactures an aftermarket replacement tube bundle coil for all Adamson Shell & Tube units, as well as, Storage Tanks that will meet all industry specifications.
Other Manufacturers We Build Are:
Bell & Gossett, Armstrong, Alco, American Standard, Cemline, Old Dominion, Taco, Patterson Kelley, ITT Standard Exchange, Reco, Thrush & Heat Exchanger USA.
Most of the time we can duplicate your tube bundle based off the model number alone. In some cases where a tag is missing, unreadable etc., we may need some dimensions & pictures of this Shell & Tube unit to determine how many passes it has and the nominal width and length. We recommend using one of our blank drawings located in the Request For Quote for recording exact measurements.
| Part # | Type |
Diameter, inches |
Working Pressure, psi. |
Max. Operating Temperature, °F |
|
|---|---|---|---|---|---|
| W-42-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-43-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-44-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-45-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-46-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-47-22-RTB | 2 Pass | 4 | 150 | 375 | Add to RFQ |
| W-42-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-43-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-44-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-45-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-46-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-47-42-RTB | 4 Pass | 4 | 150 | 375 | Add to RFQ |
| W-62-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-63-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-64-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-65-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-66-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-67-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-68-23-RTB | 2 Pass | 6 | 150 | 375 | Add to RFQ |
| W-62-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-63-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-64-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-65-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-66-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-67-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-68-43-RTB | 4 Pass | 6 | 150 | 375 | Add to RFQ |
| W-82-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-83-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-84-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-85-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-86-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-87-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-88-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-89-24-RTB | 2 Pass | 8 | 150 | 375 | Add to RFQ |
| W-82-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-83-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-84-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-85-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-86-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-87-44-RTB | 4 Pass | 8 | 150 | 375 | Add to RFQ |
| W-88-44-RTB | 4 Pass | 8 | 375 | Add to RFQ | |
| W-89-44-RTB | 4 Pass | 8 | 375 | Add to RFQ | |
| W-102-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-103-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-104-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-105-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-106-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-107-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-108-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-109-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-1010-25-RTB | 2 Pass | 10 | 375 | Add to RFQ | |
| W-102-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-103-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-104-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-105-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-106-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-107-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-108-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-109-45-RTB | 4 Pass | 10 | 375 | Add to RFQ | |
| W-1010-45-RTB | 4 Pass | 10 | 375 | Add to RFQ |
