Ames | Scotch Marine Boiler Handhole Plate Assemblies In Stock

Item Name: Ames & Cyclotherm Handhole Assemblies
Description: has the solution for your handhole and manhole plate needs. Many of the popular sizes are listed below, but if you do not see the size you need, call us and we can get it!


We carry both clip and stud style plates, which come with a neoprene handhole gasket with every plate. Stainless steel plates are available too!


All handhole and manhole plates listed are flat coded plates with the exception of the 11 x 15 which also has a non-coded version. Non-Code manhole assemblies have been proof tested to 600 PSI. These lightweight, single bolt and crab manholes have been designed for use in Non-Code vessels of low pressure, requiring frequent inspection and/or cleaning. Pressures should not exceed 15 PSI working pressure.


All manholes are furnished with a neoprene gasket rated from -20°F to 170°F. (-29°C to 76°C)

Shipping Time: 1-3 Business Day
Ames & Cyclotherm Handhole Assemblies (Less Ring)
Part # Size Type & Style Curved Radius
PHH2BC 3-3/8 x 4-3/8 Elliptical / Curved 27-30R 5.00 Add to RFQ
PHH2AC 3-3/8 x 4-3/8 Elliptical / Curved 21-24R 5.00 Add to RFQ
PHH3BC 3-1/2 X 4-1/2 Elliptical / Curved 42R 5.00 Add to RFQ
PHH3AC 3-1/2 X 4-1/2 Elliptical / Curved 36R 5.00 Add to RFQ
PHH1BC 2-3/4 x 3-3/4 Elliptical / Curved 18R 5.00 Add to RFQ
PHH1AC 2-3/4 x 3-3/4 Elliptical / Curved 15R 5.00 Add to RFQ
PHHA30C 2-5/8 X 3-5/8 Elliptical / Flat A30 5.00 Add to RFQ
