Motors: Heavy-duty, ball bearing, close-coupled pump motors with stainless steel shaft. 3450 RPM for greater efficiency and more economical operation. Float Switch: Two-pole, drip proof case, stainless steel float and float rod, double-break silver-to-silver contacts. Float travel adjustment is easy, visible and accessible. Automatic Venting: Provides for efficient operation and long life by venting air and flushing seal area. Large Tanks: Plenty of capacity for maximum rating of pump. Return inlet is low. Occupies a minimum of floor space. Centrifugal Pump: Offers a wide range of pressures and GPM. Unique design features provide for ease of servicing. Impeller: Made of brass for long life. Efficient design provides maximum capacity, minimum motor load. “SterlSeal” Pump Seal (A): Features the ultimate in ceramic technology for exceptionally long life. Because the seal runs on the bronze impeller hub, the motor shaft is literally outside the pump.
Standard Features:
• Heavy gauge steel receivers • Simplex Unit
• Bronze fitted centrifugal pumps • Energy efficient 3450 RPM motors
• Automatic venting • “Sterl-Seal” ceramic pump seal (250°F)
• Heavy-duty float switch • Wide range of options and accessories
SHIPPING WEIGHT - 160 LBS.
Part # |
Capacity (EDR), ft² |
Type |
Receiver Size |
Motor Power |
Pump Capacity |
Inlet, inches |
Unit Weight (Lbs.) |
Price | Qty | ||
---|---|---|---|---|---|---|---|---|---|---|---|
|
4028-G | 8000 | Simplex | 8 gal | 1/3 hp | 12 gpm @ 20 Psi | 2 | 95.75 | $1,615.00 | Add to Cart Add to RFQ | |
|
4128-G | 8000 | Simplex | 15 gal | 1/3 hp | 12 gpm @ 20 Psi | 2 | 127.65 | $1,856.00 | Add to Cart Add to RFQ |
