Hoffman Condensate Units - Watchman Series In Stock

Item Name: Watchman® Series WCS® Steel Receiver Condensate Unit
Manufacturer:
Hoffman pump
Description:

Designed for 6,000–12,000 sq. ft. EDR systems, these condensate units are available in simplex or duplex configurations with low-height NPT inlets for easy return piping. Separate NPT vent and drain connections support safe operation.



Key Features:

  • Cast iron receivers (6, 9, 14, 23 gal) with 20-year corrosion warranty
  • Close-coupled centrifugal pumps with bronze impeller, bronze wear ring, and mechanical seals rated to 250°F
  • Vertically mounted, drip-proof motors with overload protection and stainless steel shafts
  • Heavy-duty, externally adjustable float switches
  • Duplex units include mechanical alternators for automatic pump staging
  • Handles condensate up to 210°F with 2' NPSH; discharge up to 30 PSIG
  • Compact footprint with flexible inlet/overflow options (14 gal)
  • Simplified installation with shorter manifolding and piping



Optional Equipment:
Inlet basket strainer, Y-strainer, wall-mounted control panels
Shipping Time: 1-3 Business Day
Express ship options available
Specifications
Part # Model # System Sq. Ft.
EDR 		Pump
Style 		Discharge
Pressure
(PSIG) 		Pump
Capacity
(GPM) 		Receiver
Capacity
(Gallons) 		Motor
(HP) 		Note for Motor
160010 WCS-6-20-B 6,000 Simplex 22 9 6 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160011 WCS-8-20-B 8,000 Simplex 21 12 9 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160012 WCS-12-20-B 12,000 Simplex 20 18 14 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160013 WCSD-12-20-B MA 12,000 Duplex 20 18 14 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
Item Name: Watchman® Series WC® Cast Iron Receiver Condensate Unit
Manufacturer:
Hoffman pump
Shipping Time: 1-3 Business Day
Express ship options available
Specifications
Part # Model # System Sq. Ft.
EDR 		Pump
Style 		Discharge
Pressure
(PSIG) 		Pump
Capacity
(GPM) 		Receiver
Capacity
(Gallons) 		Motor
(HP) 		Note for Motor
160029 WC-6-20-B 6,000 Simplex 22 9 6 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160030 WC-8-20-B 8,000 Simplex 21 12 9 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160031 WC-12-20-B 12,000 Simplex 20 18 14 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160032 WCD-12-20-B MA 12,000 Duplex 20 18 14 1/3 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
160036 WCD30-30 B-MA 30,000 Duplex 30 30 23 1 3500 RPM, 1 phase 115. (may be
field converted to 230 V, 1 phase) 		Add to RFQ
