Fabtek Stainless Steel 25 Gallon Tank Washdown Condensate Units In Stock

Manufacturer:
Fabtek
Description:

The Washdown Duty Stainless Steel Condensate Units include a NEMA 4 Float Switch (Simplex) or a NEMA 4 Mechanical Alternator (Duplex). The Float Switches/Alternators are Epoxy Coated & Gasketed for Watertight Service. The tank connection bushings for the switches are of Stainless Steel Construction. Stainless Steel Seal Vent Lines and fittings are provided. Washdown Duty Motors are available with a USDA approved White Epoxy Finish or with all 300 Series Stainless Steel Exterior Components both of which meet IP55 enclosure protection requirements. For more severe environments, Premium Stainless Steel Motors are Available with IEEE 841 Severe Duty Features and IP56 Enclosure Protection. Clean Room compliant WashDown motors with Epoxy Resin Winding Encapsulation, Pre-Lubricated Double Sealed Bearings and Output Shaft Seal Bearing Isolators can be provided as well. Control Panels are available for Single Phase** or Three Phase Power for 60Hz 115/208/230/460/575VAC voltage. Panels are available in NEMA 4 Steel, NEMA 4X Fiberglass, NEMA 4X Stainless Steel and Clean Room Compliant NEMA 4X “Washguard” Stainless Steel Enclosures. Panels are mounted to receivers using SS Brackets and wired to pumps and switches using liquid-tite conduit. Panels can also be shipped loose for remote mounting. *5 year warranty excludes the mechanical seal. Pump Motors carry their manufacturer’s warranty only. **Control Panels are not required for Single Phase Power unless High Level Alarm Circuit and Annunciation are desired. Single Phase Pumps will run Directly from Pilot Signal from NEMA 4 Float Switch/Alternator

Item Name: Simplex Unit
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Lead Time: Quick Ship Times Available upon Request with Standard Shipping 5 to 7 Days.
25 Gallon Simplex 15 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
25 gal 15000 15 15 1/3 25150503C4AB1S Simplex 1 phase Add to RFQ
25 gal 15000 15 15 1/3 25150503C4AB3S Simplex 3 phase Add to RFQ
25 gal 15000 15 20 1/3 25200503C4BC1S Simplex 1 phase Add to RFQ
25 gal 15000 15 20 1/3 25200503C4BC3S Simplex 3 phase Add to RFQ
25 gal 15000 15 25 1 25251010C5AB1S Simplex 1 phase Add to RFQ
25 gal 15000 15 25 1 25251010C5AB3S Simplex 3 phase Add to RFQ
25 gal 15000 15 30 1 25301010C5AB1S Simplex 1 phase Add to RFQ
25 gal 15000 15 30 1 25301010C5AB3S Simplex 3 phase Add to RFQ
25 gal 15000 15 40 1-1/2 25401515C6AB1S Simplex 1 phase Add to RFQ
25 gal 15000 15 40 1-1/2 25401515C6AB3S Simplex 3 phase Add to RFQ
25 gal 15000 15 50 2 25502020C6BC1S Simplex 1 phase Add to RFQ
25 gal 15000 15 50 2 25502020C6BC3S Simplex 3 phase Add to RFQ
25 Gallon Simplex 22 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
25 gal 22000 22 15 1/3 25150503C4BC1S Simplex 1 phase Add to RFQ
25 gal 22000 22 15 1/3 25150503C4BC3S Simplex 3 phase Add to RFQ
25 gal 22000 22 20 1/2 25200505C4AB1S Simplex 1 phase Add to RFQ
25 gal 22000 22 20 1/2 25200505C4AB3S Simplex 3 phase Add to RFQ
25 gal 22000 22 25 1 25251010C5BC1S Simplex 1 phase Add to RFQ
25 gal 22000 22 25 1 25251010C5BC3S Simplex 3 phase Add to RFQ
25 gal 22000 22 30 1 25301010C5CD1S Simplex 1 phase Add to RFQ
25 gal 22000 22 30 1 25301010C5CD3S Simplex 3 phase Add to RFQ
25 gal 22000 22 40 2 25401515C6BC1S Simplex 1 phase Add to RFQ
25 gal 22000 22 40 2 25401515C6BC3S Simplex 3 phase Add to RFQ
25 gal 22000 22 50 3 25503030C6CD3S Simplex 3 phase Add to RFQ
Item Name: Duplex Unit
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Lead Time: Quick Ship Times Available upon Request with Standard Shipping 5 to 7 Days.
25 Gallon Duplex 15 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
25 gal 15000 15 15 1/3 25150503C4AB1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 15 1/3 25150503C4AB3D Duplex 3 Phase Add to RFQ
25 gal 15000 15 20 1/3 25200503C4BC1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 20 1/3 25200503C4BC3D Duplex 3 Phase Add to RFQ
25 gal 15000 15 25 1 25251010C5AB1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 25 1 25251010C5AB3D Duplex 3 Phase Add to RFQ
25 gal 15000 15 30 1 25301010C5AB1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 30 1 25301010C5AB3D Duplex 3 Phase Add to RFQ
25 gal 15000 15 40 1-1/2 25401515C6AB1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 40 1-1/2 25401515C6AB3D Duplex 3 Phase Add to RFQ
25 gal 15000 15 50 2 25502020C6BC1D Duplex 1 Phase Add to RFQ
25 gal 15000 15 50 2 25502020C6BC3D Duplex 3 Phase Add to RFQ
25 Gallon Duplex 22 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
25 gal 22000 22 15 1/3 25150503C4BC1D Duplex 1 Phase Add to RFQ
25 gal 22000 22 15 1/3 25150503C4BC3D Duplex 3 Phase Add to RFQ
25 gal 22000 22 20 1/2 25200505C4AB1D Duplex 1 Phase Add to RFQ
25 gal 22000 22 20 1/2 25200505C4AB3D Duplex 3 Phase Add to RFQ
25 gal 22000 22 25 1 25251010C5BC1D Duplex 1 Phase Add to RFQ
25 gal 22000 22 25 1 25251010C5BC3D Duplex 3 Phase Add to RFQ
25 gal 22000 22 30 1 25301010C5CD3D Duplex 1 Phase Add to RFQ
25 gal 22000 22 30 1 25301010C5CD3D Duplex 3 Phase Add to RFQ
25 gal 22000 22 40 2 25401515C6BC1D Duplex 1 Phase Add to RFQ
25 gal 22000 22 40 2 25401515C6BC3D Duplex 3 Phase Add to RFQ
25 gal 22000 22 50 3 25503030C6CD3D Duplex 3 Phase Add to RFQ
