Fabtek Stainless Steel 70 Gallon Tank Washdown Condensate Units In Stock

Manufacturer:
Fabtek
Description:

The Washdown Duty Stainless Steel Condensate Units include a NEMA 4 Float Switch (Simplex) or a NEMA 4 Mechanical Alternator (Duplex). The Float Switches/Alternators are Epoxy Coated & Gasketed for Watertight Service. The tank connection bushings for the switches are of Stainless Steel Construction. Stainless Steel Seal Vent Lines and fittings are provided. Washdown Duty Motors are available with a USDA approved White Epoxy Finish or with all 300 Series Stainless Steel Exterior Components both of which meet IP55 enclosure protection requirements. For more severe environments, Premium Stainless Steel Motors are Available with IEEE 841 Severe Duty Features and IP56 Enclosure Protection. Clean Room compliant WashDown motors with Epoxy Resin Winding Encapsulation, Pre-Lubricated Double Sealed Bearings and Output Shaft Seal Bearing Isolators can be provided as well. Control Panels are available for Single Phase** or Three Phase Power for 60Hz 115/208/230/460/575VAC voltage. Panels are available in NEMA 4 Steel, NEMA 4X Fiberglass, NEMA 4X Stainless Steel and Clean Room Compliant NEMA 4X “Washguard” Stainless Steel Enclosures. Panels are mounted to receivers using SS Brackets and wired to pumps and switches using liquid-tite conduit. Panels can also be shipped loose for remote mounting. *5 year warranty excludes the mechanical seal. Pump Motors carry their manufacturer’s warranty only. **Control Panels are not required for Single Phase Power unless High Level Alarm Circuit and Annunciation are desired. Single Phase Pumps will run Directly from Pilot Signal from NEMA 4 Float Switch/Alternator

Item Name: Simplex Unit
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Lead Time: Quick Ship Times Available upon Request with Standard Shipping 5 to 7 Days.
70 Gallon Simplex 60 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
70 gal 60000 60 15 3/4 70150707C4EF1S Simplex 1 Phase Add to RFQ
70 gal 60000 60 15 3/4 70150707C4EF3S Simplex 3 Phase Add to RFQ
70 gal 60000 60 20 1 70201010C4DE1S Simplex 1 Phase Add to RFQ
70 gal 60000 60 20 1 70201010C4DE3S Simplex 3 Phase Add to RFQ
70 gal 60000 60 25 2 70252020C5DE1S Simplex 1 Phase Add to RFQ
70 gal 60000 60 25 2 70252020C5DE3S Simplex 3 Phase Add to RFQ
70 gal 60000 60 30 2 70302020C5CD1S Simplex 1 Phase Add to RFQ
70 gal 60000 60 30 2 70302020C5CD3S Simplex 3 Phase Add to RFQ
70 gal 60000 60 40 3 70403030C6BC3S Simplex 3 Phase Add to RFQ
70 gal 60000 60 50 3 70503VA612SS3S Simplex 3 Phase Add to RFQ
70 Gallon Simplex 75 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
70 gal 75000 75 15 1 70151010C4DE1S Simplex 1 Phase Add to RFQ
70 gal 75000 75 15 1 70151010C4DE3S Simplex 3 Phase Add to RFQ
70 gal 75000 75 20 1-1/2 70201515C4EF1S Simplex 1 Phase Add to RFQ
70 gal 75000 75 20 1-1/2 70201515C4EF3S Simplex 3 Phase Add to RFQ
70 gal 75000 75 25 2 70252VA612SS1S Simplex 1 Phase Add to RFQ
70 gal 75000 75 25 2 70252VA612SS3S Simplex 3 Phase Add to RFQ
70 gal 75000 75 30 3 70303VA612SS3S Simplex 3 Phase Add to RFQ
70 gal 75000 75 40 3 70403VA612SS3S Simplex 3 Phase Add to RFQ
70 gal 75000 75 50 5 70505VA715SS3S Simplex 3 Phase Add to RFQ
Item Name: Duplex Unit
Description:

Stainless Steel Condensate Return Unit

  • 304 Stainless Steel Receivers with 20 Year Warranty due to corrosion.
  • 304 SS Vertical Flange mounted centrifugal pumps.
  • Heavy Duty SS Sight Gauge Valve Assembly
  • Nema 1 Float Switch ( Simplex )
  • Nema 1 Mechanical Alternator (Duplex)
  • TEFC Motor Enclosures
  • 1,000 - 150,000 Sq. Ft. EDR
  • 2,500 - 27,500  PPH
  • Floor Mounted units are rated for 200º F condensate and up to 210ºF
Lead Time: Quick Ship Times Available upon Request with Standard Shipping 5 to 7 Days.
70 Gallon Duplex 60 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
70 gal 60000 60 15 3/4 70150707C4EF1D Duplex 1 Phase Add to RFQ
70 gal 60000 60 15 3/4 70150707C4EF3D Duplex 3 Phase Add to RFQ
70 gal 60000 60 20 1 70201010C4DE1D Duplex 1 Phase Add to RFQ
70 gal 60000 60 20 1 70201010C4DE3D Duplex 3 Phase Add to RFQ
70 gal 60000 60 25 2 70252020C5DE1D Duplex 1 Phase Add to RFQ
70 gal 60000 60 25 2 70252020C5DE3D Duplex 3 Phase Add to RFQ
70 gal 60000 60 30 2 70302020C5CD1D Duplex 1 Phase Add to RFQ
70 gal 60000 60 30 2 70302020C5CD3D Duplex 3 Phase Add to RFQ
70 gal 60000 60 40 3 70403030C6BC3D Duplex 3 Phase Add to RFQ
70 gal 60000 60 50 3 70503VA612SS3D Duplex 3 Phase Add to RFQ
70 Gallon Duplex 75 Gpm Model Single & Three Phase
Tank Size EDR (Sq. Ft.) GPM PSIG HP Model # Unit
70 gal 75000 75 15 1 70151010C4DE1D Duplex 1 Phase Add to RFQ
70 gal 75000 75 15 1 70151010C4DE3D Duplex 3 Phase Add to RFQ
70 gal 75000 75 20 1-1/2 70201515C4EF1D Duplex 1 Phase Add to RFQ
70 gal 75000 75 20 1-1/2 70201515C4EF3D Duplex 3 Phase Add to RFQ
70 gal 75000 75 25 2 70252VA612SS1D Duplex 1 Phase Add to RFQ
70 gal 75000 75 25 2 70252VA612SS3D Duplex 3 Phase Add to RFQ
70 gal 75000 75 30 3 70303VA612SS3D Duplex 3 Phase Add to RFQ
70 gal 75000 75 40 3 70403VA612SS3D Duplex 3 Phase Add to RFQ
70 gal 75000 75 50 5 70505VA715SS3D Duplex 3 Phase Add to RFQ
