The Stuffing Box – or as we prefer to call it, Sealed Service - consists of extra packing around the piston/plunger to prevent those little drips that happen with all float valves – this is most commonly used when the valve is positioned outside of the tank where drippage could make floors wet or cause damage to other items.
Item # |
Valve Size |
Float Size |
Float Rod Size |
Max. Inlet Pressure |
Description | Service | Price | Qty | |
---|---|---|---|---|---|---|---|---|---|
ACF-50 | 1/2" | 5" | 1/4" Npt x 16" | 100 lbs |
1/2" Angle Valve Complete w/ Rod & Float |
Cold | $375.50 | Add to Cart | |
ACF-75 | 3/4" | 5" | 1/4" Npt x 16" | 100 lbs |
3/4" Angle Valve Complete w/ Rod & Float |
Cold | $375.50 | Add to Cart | |
ACF-100 | 1" | 6" | 1/4" Npt x 16" | 100 lbs |
1" Angle Valve Complete w/ Rod & Float |
Cold | $435.50 | Add to Cart | |
ACF-125 | 1-1/4" | 6" | 1/4" Npt x 18" | 100 lbs |
1-1/4" Angle Valve Complete w/ Rod & Float |
Cold | $515.25 | Add to Cart | |
ACF-150 | 1-1/2" | 6" | 1/4" Npt x 18" | 100 lbs |
1-1/2" Angle Valve Complete w/ Rod & Float |
Cold | $578.00 | Add to Cart | |
ACF-200 | 2" | 8" | 1/4" Npt x 20" | 75 lbs |
2" Angle Valve Complete w/ Rod & Float |
Cold | $1,072.25 | Add to Cart | |
ACF-300 | 3" | 9" | 3/8" Npt x 24" | 75 lbs |
3" Angle Valve Complete w/ Rod & Float |
Cold | $1,532.00 | Add to Cart | |
ACFB-50 | 1/2" | 5" | 1/4" Npt x 16" | 100 lbs |
1/2" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$465.75 | Add to Cart | |
ACFB-75 | 3/4" | 5" | 1/4" Npt x 16" | 100 lbs |
3/4" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$465.50 | Add to Cart | |
ACFB-100 | 1" | 6" | 1/4" Npt x 16" | 100 lbs |
1" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$527.50 | Add to Cart | |
ACFB-125 | 1-1/4" | 6" | 1/4" Npt x 18" | 100 lbs |
1-1/4" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$636.69 | Add to Cart | |
ACFB-150 | 1-1/2" | 6" | 1/4" Npt x 18" | 100 lbs |
1-1/2" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$690.50 | Add to Cart | |
ACFB-200 | 2" | 8" | 1/4" Npt x 20" | 75 lbs |
2" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$1,205.00 | Add to Cart | |
ACFB-300 | 3" | 9" | 3/8" Npt x 24" | 75 lbs |
3" Angle Valve Complete w/ Rod & Float |
Cold w/ Sealed Service |
$1,715.00 | Add to Cart |
