Bell & Gossett SU Tube Bundle Coil Steam to Water In Stock

How Tube Bundles Work:

Tube bundles are replaceable coils inside the shell of the Heat Exchanger. This is the most common part that fails and most often the U-tubes can be vulnerable to corrosion and failure. The tube bundle coil can be manufactured with many types of materials including copper, CuNi, stainless steel along with naval brass and carbon steel.

Boilersupplies.com manufactures an aftermarket replacement tube bundle coil for all Bell & Gossett Shell & Tube units, as well as, Storage Tanks that will meet all industry specifications.



Other Manufacturers We Build Are:

Bell & Gossett, Armstrong, Alco, American Standard, Cemline, Old Dominion, Taco, Patterson Kelley, ITT Standard Exchange, Reco, Thrush & Heat Exchanger USA.

Measuring Tube Bundle Coil Still in the Heat Exchanger:

Most of the time we can duplicate your tube bundle based off the model number alone. In some cases where a tag is missing, unreadable etc., we may need some dimensions & pictures of this Shell & Tube unit to determine how many passes it has and the nominal width and length. We recommend using one of our blank drawings located in the Request For Quote for recording exact measurements.


Item Name: Bell & Gossett SU Tube bundle Coils Steam to Water
Manufacturer:
Bell & Gossett
Shipping Time: 1-3 Business Day
Express ship options available
Specifications
Model # Part # Pass
Type 		Diameter,
inches 		Tube Sheet
Material 		Tube
Material
SU42-2-RTB 5-260-04-024-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU43-2-RTB 5-260-04-036-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU44-2-RTB 5-260-04-048-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU45-2-RTB 5-260-04-060-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU46-2-RTB 5-260-04-072-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU47-2-RTB 5-260-04-084-011 2 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU42-4-RTB 5-260-04-024-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU43-4-RTB 5-260-04-036-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU44-4-RTB 5-260-04-048-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU45-4-RTB 5-260-04-060-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU46-4-RTB 5-260-04-072-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU47-4-RTB 5-260-04-084-012 4 Pass 4 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU62-2-RTB 5-260-06-024-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU63-2-RTB 5-260-06-036-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU64-2-RTB 5-260-06-048-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU65-2-RTB 5-260-06-060-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU66-2-RTB 5-260-06-072-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU67-2-RTB 5-260-06-084-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU68-2-RTB 5-260-06-096-001 2 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU62-4-RTB 5-260-06-024-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU63-4-RTB 5-260-06-036-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU64-4-RTB 5-260-06-048-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU65-4-RTB 5-260-06-060-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU66-4-RTB 5-260-06-072-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU67-4-RTB 5-260-06-084-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU68-4-RTB 5-260-06-096-002 4 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU62-6-RTB 5-260-06-024-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU63-6-RTB 5-260-06-036-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU64-6-RTB 5-260-06-048-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU65-6-RTB 5-260-06-060-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU66-6-RTB 5-260-06-072-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU67-6-RTB 5-260-06-084-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU68-6-RTB 5-260-06-096-XXX 6 Pass 6 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU82-2-RTB 5-260-08-024-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU83-2-RTB 5-260-08-036-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU84-2-RTB 5-260-08-048-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU85-2-RTB 5-260-08-060-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU86-2-RTB 5-260-08-072-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU87-2-RTB 5-260-08-084-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU88-2-RTB 5-260-08-096-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU89-2-RTB 5-260-08-108-001 2 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU82-4-RTB 5-260-08-024-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU83-4-RTB 5-260-08-036-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU84-4-RTB 5-260-08-048-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU85-4-RTB 5-260-08-060-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU86-4-RTB 5-260-08-072-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU87-4-RTB 5-260-08-084-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU88-4-RTB 5-260-08-096-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU89-4-RTB 5-260-08-108-002 4 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU82-6-RTB 5-260-08-024-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU83-6-RTB 5-260-08-036-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU84-6-RTB 5-260-08-048-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU85-6-RTB 5-260-08-060-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU86-6-RTB 5-260-08-072-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU87-6-RTB 5-260-08-084-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU88-6-RTB 5-260-08-096-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU89-6-RTB 5-260-08-108-XXX 6 Pass 8 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU102-2-RTB 5-260-10-024-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU103-2-RTB 5-260-10-036-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU104-2-RTB 5-260-10-048-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU105-2-RTB 5-260-10-060-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU106-2-RTB 5-260-10-072-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU107-2-RTB 5-260-10-084-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU108-2-RTB 5-260-10-096-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU109-2-RTB 5-260-10-108-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU1010-2-RTB 5-260-10-120-001 2 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU102-4-RTB 5-260-10-024-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU103-4-RTB 5-260-10-036-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU104-4-RTB 5-260-10-048-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU105-4-RTB 5-260-10-060-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU106-4-RTB 5-260-10-072-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU107-4-RTB 5-260-10-084-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU108-4-RTB 5-260-10-096-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU109-4-RTB 5-260-10-108-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU1010-4-RTB 5-260-10-120-002 4 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU102-6-RTB 5-260-10-024-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU103-6-RTB 5-260-10-036-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU104-6-RTB 5-260-10-048-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU105-6-RTB 5-260-10-060-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU106-6-RTB 5-260-10-072-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU107-6-RTB 5-260-10-084-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU108-6-RTB 5-260-10-096-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU109-6-RTB 5-260-10-108-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
SU1010-6-RTB 5-260-10-120-XXX 6 Pass 10 Carbon Steel Copper Tubing (3/4" OD) .049 Wall Add to RFQ
