Aluminum chain wheel with aluminum chain guide. Use these with link style welded chain where the use of this chain is preferred.
Chainwheel uses #2 Hot Dipped Galvanized Welded Machine Chain.
*No Masterlink for Pocketwheels*
| Babbitt Part # / Wheel Size # | ARG-1.5P | ARG-2P | ARG-2.5P | ARG-3P | ARG-3.5P | ARG-4P | ARG-4.5P |
|---|---|---|---|---|---|---|---|
| A- OVERALL HEIGHT | 7-3/4" | 10-1/2" | 12-1/2" | 15-1/2" | 18-1/2" | 21-1/2" | 25-3/4" |
| B- INNER BOLT CIRCLE | 3-1/2" | 4-1/2" | 5-1/2" | 8-1/2" | 11-1/2" | 11-1/2" | 14-1/2" |
| C- OUTER BOLT CIRCLE | 5" | 6-5/8" | 9-1/4" | 12-3/8" | 15-1/2" | 17-3/4" | 21-1/4" |
| D- HUB OPENING (DIA) | 1" | 2-1/8" | 2-1/8" | 2-1/8" | 3" | 3" | 3" |
| E- SLOT SIZE (WIDTH) | 3/8" | 3/8" | 7/16" | 7/16" | 7/16" | 5/8" | 5/8" |
| F- REAR OPENING | 1-7/8" | 3-1/8" | 3-1/2" | 3-1/2" | 4-7/8" | 4-7/8" | 4-5/8" |
| G- HUB DEPTH (SHOULDER TO REAR) | 1-7/16" | 1-3/8" | 1-3/4" | 1-7/8" | 1-7/8" | 1-7/8" | 1-7/8" |
| H- RIM THICKNESS | 1-1/8" | 1-1/8" | 1-1/4" | 1-1/4" | 1-1/4" | 1-1/2" | 1-1/2" |
| I- OVERALL DEPTH | 2-3/8" | 2-3/8" | 2-5/8" | 2-5/8" | 3-1/8" | 3-1/8" | 3-1/8" |
| Item # |
Description Chain Operator |
Valve Handwheel OD (inches) |
Chain Operator # |
Wheel Rim OD (inches) |
Uses Chain Size |
Price | |
|---|---|---|---|---|---|---|---|
| ARG-1.5P |
Aluminum Pocketwheel Only ARG-1.5P |
6 - 7-1/2" | 1.5 | 7-1/2" | 2/0 | $180.95 | Add to RFQ |
| ARG-2P |
Aluminum Pocketwheel Only ARG-2P |
7-3/4 - 9" | 2 | 9" | 2/0 | $227.95 | Add to RFQ |
| ARG-2.5P |
Aluminum Pocketwheel Only ARG-2.5P |
9-1/4 - 12-1/2" | 2.5 | 12" | 2/0 | $315.00 | Add to RFQ |
| ARG-3P |
Aluminum Pocketwheel Only ARG-3P |
12-3/4 - 15-1/2" | 3 | 15-1/2" | 2/0 | $355.95 | Add to RFQ |
| ARG-3.5P |
Aluminum Pocketwheel Only ARG-3.5P |
15-3/4 - 19" | 3.5 | 18-1/2" | 2/0 | $752.95 | Add to RFQ |
| ARG-4P |
Aluminum Pocketwheel Only ARG-4P |
19-1/4 - 22" | 4 | 21-1/2" | 2/0 | $1,225.00 | Add to RFQ |
| ARG-4.5P |
Aluminum Pocketwheel Only ARG-4.5P |
22-1/2 - 26" | 4.5 | 25-3/4" | 2/0 | $1,575.00 | Add to RFQ |
| Item # |
Uses Chain Trade Size |
Product Description | Price | |
|---|---|---|---|---|
| GCW-1-5P | 2/0 | Chain Used For All Pocket Wheel Models | $17.20 | Add to RFQ |
