The Watson McDaniel FTT Series Float & Thermostatic Steam Traps are used in drip and process applications, industrial and HVAC process equipment. The excellent air handling capabilities of float and thermostatic traps make them a better choice than bucket traps for applications requiring quick system start-up. These traps have in-line pipe connections. Used on unit heaters, textile machines, heat exchangers, and other medium sized process equipment.
Applications : Series FTT Steam Traps are designed to freely remove condensate and non-condensables in steam systems. Services Unit & Space Heaters | Textile Machinery | Pressing Machines | Steam Process Equipment | Steam Main Drip Stations | Heat Exchangers | Coils Materials 1 - Body - Ductile Iron 2 - Cover - Ductile Iron 3 - Gasket - Garlock 3400 4 - Cover Screws - Steel, GR 5 5 - Float - 304 SS 6 - Internals - 300 Series SS 7 - Thermostat - SS 8 - Valve Seat - 17-4 PH SS 9 - Valve Disc - 420F SS Maximum Operating Temperature Saturated Steam Temperature Maximum Allowable Pressure (PMA): 250 PSI Maximum Allowable Temperature (TMA): 450°F
Part # | Size |
Max Oper. Press. |
Connection | Weight |
Cross Reference List (Spirax Sarco) |
Cross Reference List (Hoffman) |
|
---|---|---|---|---|---|---|---|
FTT-065-12-N | 1/2" | 65 | NPT | 6 | FT14-4.5 | Bear | Add to RFQ |
FTT-065-13-N | 3/4" | 65 | NPT | 6 | FT14-4.5 | Bear | Add to RFQ |
FTT-065-14-N | 1" | 65 | NPT | 16 | FT14-4.5 | Bear | Add to RFQ |
FTT-065-16-N | 1-1/2" | 65 | NPT | 38 | FT14-4.5 | Bear | Add to RFQ |
FTT-065-17-N | 2" | 65 | NPT | 42 | FT14-4.5 | Bear | Add to RFQ |
FTT-145-12-N | 1/2" | 145 | NPT | 6 | FT14-10 | Bear | Add to RFQ |
FTT-145-13-N | 3/4" | 145 | NPT | 6 | FT14-10 | Bear | Add to RFQ |
FTT-145-14-N | 1" | 145 | NPT | 16 | FT14-10 | Bear | Add to RFQ |
FTT-145-16-N | 1-1/2" | 145 | NPT | 38 | FT14-10 | Bear | Add to RFQ |
FTT-145-17-N | 2" | 145 | NPT | 42 | FT14-10 | Bear | Add to RFQ |
FTT-225-12-N | 1/2" | 225 | NPT | 6 | FT14-14 | Bear | Add to RFQ |
FTT-225-13-N | 3/4" | 225 | NPT | 6 | FT14-14 | Bear | Add to RFQ |
FTT-225-14-N | 1" | 225 | NPT | 16 | FT14-14 | Bear | Add to RFQ |
FTT-250-16-N | 1-1/2" | 250 | NPT | 38 | FT14-14 | Bear | Add to RFQ |
FTT-250-16-N | 2" | 250 | NPT | 43 | FT14-14 | Bear | Add to RFQ |
Part # | Size |
Max Oper. Press. |
Connection | Weight |
Cross Reference List (Spirax Sarco) |
|
---|---|---|---|---|---|---|
FTT-065-12-N(SLR) | 1/2" | 65 | NPT | 6 | FT14-4.5C | Add to RFQ |
FTT-065-13-N(SLR) | 3/4" | 65 | NPT | 6 | FT14-4.5C | Add to RFQ |
FTT-065-14-N(SLR) | 1" | 65 | NPT | 16 | FT14-4.5C | Add to RFQ |
FTT-145-12-N(SLR) | 1/2" | 145 | NPT | 6 | FT14-10C | Add to RFQ |
FTT-145-13-N(SLR) | 3/4" | 145 | NPT | 6 | FT14-10C | Add to RFQ |
FTT-145-14-N(SLR) | 1" | 145 | NPT | 16 | FT14-10C | Add to RFQ |
FTT-225-13-N(SLR) | 1/2" | 225 | NPT | 6 | FT14-14C | Add to RFQ |
FTT-225-13-N(SLR) | 3/4" | 225 | NPT | 6 | FT14-14C | Add to RFQ |
FTT-225-14-N(SLR) | 1" | 225 | NPT | 16 | FT14-14C | Add to RFQ |
